SCOPE OF ACCREDITATION TO ISO/IEC 17025:2017, ANSI/NCSL Z540-1-1994 (R2002) AND ANSI/NCSL Z540.3-2006 (R2013)
Technical Maintenance, Inc.
3248 Forest View Road
Rockford, IL 61109
Scott Chamberlain 779-774-3877
CALIBRATION
Valid to: September 20, 2019 Certificate Number: AC-2080.03
Acoustics and Vibration
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Accelerometers – Acceleration (7 to 200) Hz (100 to 2 500) Hz (2.5 to 10) kHz |
(0.01 to 10) g |
1.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 1.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 2.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Accelerometer Calibrator |
Chemical Quantities
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
pH3 |
(4, 7, 10) pH |
0.019 pH |
Buffer Solutions |
|
Conductivity3 |
99.8 µS 998 µS 10 007 µS |
0.38 µS 4.1 µS 37 µS |
Conductivity Solutions |
Electrical – DC/Low Frequency
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
DC Current – Generate3 |
Up to 220 µA (0.22 to 2.2) mA (2.2 to 22) mA (22 to 220) mA (0.22 to 2.2) A |
55 µA/A + 6 nA 50 µA/A + 7 nA 50 µA/A + 40 nA 60 µA/A + 0.7 µA 98 µA/A + 12 µA |
Fluke 5522A |
|
DC Current – Generate3 |
(2.2 to 11) A |
0.037{3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 480 µA |
Fluke 5720A/5725A |
|
DC Current – Generate3 |
(11 to 20.5) A |
0.11 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 750 µA |
Fluke 5522A |
|
DC Current – Generate3 Clamp Only |
(20.5 to 1000) A |
0.9 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Fluke 5522A/Coil5500A |
|
DC Current – Measure3 |
Up to 100 nA 100 nA to 1 µA (1 to 10) µA (10 to 100) µA 100 µA to 10 mA (10 to 100) mA 100 mA to 1 A |
36 μA/A + 0.04 nA 24 μA/A + 0.04 nA 24 μA/A + 0.1 nA 24 μA/A + 0.8 nA 25 μA/A + 0.05 μA 43 μA/A + 0.5 μA 0.14 mA/A + 10 μA |
Agilent 3458A |
|
DC Current – Measure3 |
(1 to 500) A |
0.32 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Current Shunt |
|
DC Voltage3 – Generate |
Up to 220 mV (0.22 to 2.2) V (2.2 to 11) V (11 to 22) V (22 to 220) V (220 to 1 100) V |
11 µV/V + 0.4 µV 8.2 µV/V + 0.7 µV 7.1 µV/V + 2.5 µV 7.1 µV/V + 4 µV 8.2 µV/V + 40 µV 10 µV/V + 0.4 mV |
Fluke 5720A |
|
DC Voltage3 – Measure |
Up to 100 mV 100 mV to 1V (1 to 10) V (10 to 100) V (100 to 1 000) V |
18 μV/V + 0.3 μV 11 μV/V + 0.3 μV 11 μV/V + 0.5 μV 13 μV/V + 30 μV 13 μV/V + 0.1 mV |
Agilent 3458A |
|
DC Voltage3 – Measure |
(1 to 120) kV |
0.37 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Ross VD120 |
Electrical – DC/Low Frequency
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
AC Voltage – Generate3 |
Up to 22 mV (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz (22 to 220) mV (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz 220 mV to 2.2 V (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz (2.2 to 22) V (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz |
0.36 mV/V + 5 µV 0.15 mV/V + 5 µV 0.13 mV/V + 5 µV 0.3 mV/V + 5 µV 0.71 mV/V + 6 µV 1.6 mV/V + 12 µV 2 mV/V + 25 µV 4 mV/V + 25 µV 0.35 mV/V + 15 µV 0.14 mV/V + 8 µV 0.12 mV/V + 8 µV 0.29 mV/V + 8 µV 0.7 mV/V + 20 µV 1.3 mV/V + 25 µV 2 mV/V + 30 µV 3.9 mV/V + 60 µV 0.51 mV/V + 50 µV 0.4 mV/V + 20 µV 0.38 mV/V + 10 µV 1.4 mV/V + 12 µV 0.41 mV/V + 40 µV 0.69 mV/V + 0.1 mV 1.5 mV/V + 0.25 mV 2.4 mV/V + 0.4 mV 0.48 mV/V + 0.5 mV 0.39 mV/V + 0.2 mV 0.38 mV/V + 70 µV 0.39 mV/V + 0.12 mV 0.4 mV/V + 0.25 mV 0.5 mV/V + 0.8 mV 1.3 mV/V + 2.5 mV 1.9 mV/V + 4 mV |
Fluke 5720A |
Electrical – DC/Low Frequency
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
AC Voltage – Generate3 |
(22 to 220) V (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz |
0.51 mV/V + 5 mV 0.4 mV/V + 2 mV 0.38 mV/V + 0.7 mV 0.39 mV/V + 1.2 mV 0.43 mV/V + 3 mV 1.4 mV/V + 20 mV 6.3 mV/V + 50 mV 12 mV/V + 0.1 V |
Fluke 5720A |
|
AC Voltage – Generate3 |
(220 to 1 100) V 40 Hz to 1 kHz (1 to 20) kHz (20 to 30) kHz (220 to 750) V (30 to 50) kHz (50 to 100) kHz |
0.38 mV/V + 0.7 mV 0.39 mV/V + 1.2 mV 0.43 mV/V + 3 mV 0.39 mV/V + 1.2 mV 0.43 mV/V + 3 mV |
Fluke 5720A/5725A |
|
AC Voltage – Measure3 |
Up to 10 mV (1 to 40) Hz (40 to 100) Hz 100 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 250) kHz 10 mV to 100 mV (1 to 40) Hz 40 Hz to 1 kHz (1 to 20) kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz 300 kHz to 1 MHz (1 to 2) MHz |
0.044 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.003 mV 0.026 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.0011 mV 0.044 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.0011 mV 0.11 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.0011 mV 0.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.0011 mV 4 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.002 mV 0.019 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.004 mV 0.019 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.002 mV 0.027 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.002 mV 0.045 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.002 mV 0.09 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.002 mV 0.31 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.01 mV 1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.01 mV 1.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.01 mV |
Agilent 3458A |
Electrical – DC/Low Frequency
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
AC Voltage – Measure3 |
100 mV to 1 V (1 to 40) Hz 40 Hz to 1 kHz (1 to 20) kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz 300 kHz to 1 MHz (1 to 2) MHz 1 V to 10 V (1 to 40) Hz 40 Hz to 1 kHz (1 to 20) kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz 300 kHz to 1 MHz (1 to 2) MHz (10 to 100) V (1 to 40) Hz 40 Hz to 1 kHz (1 to 20) kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz 300 kHz to 1 MHz (100 to 700) V (1 to 40) Hz 40 Hz to 1 kHz (1 to 20) kHz (20 to 50) kHz (50 to 100) kHz |
0.019 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.04 mV 0.019 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 mV 0.027 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 mV 0.045 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 mV 0.09 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 mV 0.31 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.1 mV 1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.1 mV 1.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.1 mV 0.019 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.0004 V 0.019 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.0002 V 0.027 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.0002 V 0.045 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.0002 V 0.09 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.0002 V 0.31 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.001 V 1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.001 V 1.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.001 V 0.026 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.002 V 0.041 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.002 V 0.038 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.002 V 0.048 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.002 V 0.13 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.002 V 0.4 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.01 V 1.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.01 V 0.05 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.04 V 0.05 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 V 0.07 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 V 0.13 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 V 0.3 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 V |
Agilent 3458A |
|
AC Voltage – Measure3 |
(1 to 85) kV (50, 60) Hz |
0.62 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Ross VD120 w/34401A |
Electrical – DC/Low Frequency
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
AC Current – Generate3 |
Up to 200 µA (10 to 20) Hz (20 to 40) Hz 40 Hz to 1 kHz (1 to 5) kHz (5 to 10) kHz (0.2 to 2.2) mA (10 to 20) Hz (20 to 40) Hz 40 Hz to 1 kHz (1 to 5) kHz (5 to 10) kHz (2.2 to 22) mA (10 to 20) Hz (20 to 40) Hz 40 Hz to 1 kHz (1 to 5) kHz (5 to 10) kHz (22 to 200) mA (10 to 20) Hz (20 to 40) Hz 40 Hz to 1 kHz (1 to 5) kHz (5 to 10) kHz (0.2 to 2.2) A 20 Hz to 1 kHz (1 to 5) kHz (5 to 10) kHz |
0.36 mA/A + 20 nA 0.25 mA/A + 12 nA 0.19 mA/A + 10 nA 0.42 mA/A + 15 nA 1.6 mA/A + 80 nA 0.36 mA/A + 50 nA 0.25 mA/A + 40 nA 0.18 mA/A + 40 nA 0.3 mA/A + 0.18 µA 1.6 mA/A + 0.8 µA 0.26 mA/A + 0.5 µA 0.24 mA/A + 0.4 µA 0.18 mA/A + 0.4 µA 0.3 mA/A + 0.7 µA 1.6 mA/A + 6 µA 0.36 mA/A + 5 µA 0.24 mA/A + 4 µA 0.18 mA/A + 3 µA 0.3 mA/A + 4 µA 1.6 mA/A + 12 µA 0.28 mA/A + 40 µA 0.6 mA/A + 0.1 mA 9.3 mA/A + 0.2 mA |
Fluke 5720A |
|
AC Current – Generate3 |
(2.2 to 11) A 40 Hz to 1 kHz (1 to 5) kHz (5 to 10) kHz |
0.81 mA/A + 0.17 mA 1.3 mA/A + 0.38 mA 4.3 mA/A + 0.75 mA |
Fluke 5720A/5725A |
|
AC Current – Generate3 |
(11 to 20.5) A (45 to 100) Hz 100 Hz to 1 kHz (1 Hz to 5) kHz |
0.1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 2 mA 0.12 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 5 mA 2.28 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 5 mA |
Fluke 5522A |
|
AC Current – Generate3 Clamp Only |
(20.5 to 1 000) A (45 to 440) Hz |
1.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.9 A |
Fluke 5520A/coil |
Electrical – DC/Low Frequency
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
AC Current – Measure3 |
Up to 100 μA (10 to 20) Hz (20 to 45) Hz 45 Hz to 1 kHz (1 to 100) mA (10 to 20) Hz (20 to 45) Hz (45 to 100) Hz 100 Hz to 5 kHz (5 to 20) kHz (20 to 50) kHz (50 to 100) kHz (0.1 to 1) A (10 to 20) Hz (20 to 45) Hz (45 to 100) Hz 100 Hz to 5 Hz (5 to 20) kHz (20 to 50) kHz |
0.41 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.03 pA 0.16 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.03 pA 0.07 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.03 pA 0.41 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 20 μA 0.16 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 20 μA 0.069 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 20 μA 0.038 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 20 μA 0.069 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 20 μA 0.41 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 40 μA 0.56 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.15 mA 0.41 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.2 mA 0.17 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.2 mA 0.087 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.2 mA 0.11 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.2 mA 0.31 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.2 mA 1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.4 mA |
Agilent 3458A |
|
AC Current – Measure3 |
(2 to 30) A Up to 1 kHz (1 to 5) kHz |
0.36 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 5.8 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Current Shunt |
|
Resistance3 – Fixed Points |
1 Ω, 1.9 Ω 10 Ω, 19 Ω 100 Ω, 190 Ω 1 kΩ, 1.9 kΩ 10 kΩ, 19 kΩ 100 kΩ, 190 kΩ 1 MΩ 1.9 MΩ 10 MΩ 19 MΩ 100 MΩ |
0.12 mΩ/Ω 31 μΩ/Ω 23 μΩ/Ω 12 μΩ/Ω 13 μΩ/Ω 14 μΩ/Ω 24 μΩ/Ω 26 μΩ/Ω 50 μΩ/Ω 59 μΩ/Ω 0.14 mΩ/Ω |
Fluke 5720A |
Electrical – DC/Low Frequency
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Resistance – Generate3 |
Up to 11 Ω (11 to 33) Ω (33 to 110) Ω (110 to 330) Ω 330 Ω to 1.1 kΩ (1.1 to 3.3) kΩ (3.3 to 11) kΩ (11 to 33) kΩ (33 to 110) kΩ (110 to 330) kΩ 0.33 MΩ to 1.1 MΩ (1.1 to 3.3) MΩ (3.3 to 11) MΩ (11 to 33) MΩ (33 to 110) MΩ (110 to 330) MΩ 330 MΩ to 1.1 GΩ |
51 μΩ/Ω + 0.01 Ω 42μΩ/Ω + 0.015 Ω 33 μΩ/Ω + 0.015 Ω 33 μΩ/Ω + 0.02 Ω 33 μΩ/Ω + 0.02 Ω 34 μΩ/Ω + 0.2 Ω 34 μΩ/Ω + 0.1 Ω 34 μΩ/Ω + 1 Ω 33 μΩ/Ω + 1 Ω 40 μΩ/Ω + 10 Ω 38μΩ/Ω + 10 Ω 70 μΩ/Ω + 0.15 kΩ 0.15 mΩ/Ω + 0.25 kΩ 0.3 mΩ/Ω + 2.5 kΩ 0.61 mΩ/Ω + 3 kΩ 3.5 mΩ/Ω + 0.1 MΩ 17 mΩ/Ω + 0.5 MΩ |
Fluke 5522A |
|
Resistance – Measure3 |
Up to 10 Ω (10 to 100) Ω 100 Ω to 1 kΩ (1 to 10) kΩ (10 to 100) kΩ 100 kΩ to 1 MΩ (1 to 10) MΩ (10 to 100) MΩ 100 MΩ to 1 GΩ |
18 μΩ/Ω + 50 μΩ 16 μΩ/Ω + 0.5 mΩ 13 μΩ/Ω + 0.5 mΩ 14 μΩ/Ω + 5 mΩ 13 μΩ/Ω + 50 mΩ 18 μΩ/Ω + 2 Ω 58 μΩ/Ω + 100 Ω 0.58 mΩ/Ω + 1 kΩ 0.59 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 10 kΩ |
Agilent 3458A |
|
Capacitance – Generate3 Fixed Points |
1 pF 10 pF 100 pF 1 000 pF |
0.41 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 017 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.13 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.32 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Agilent 16380A |
|
Capacitance – Generate3 |
(220 to 400) pF (0.4 to 3.3) nF (3.3 to 33) nF (33 to 330) nF (0.33 to 3.3) μF (3.3 to 11) μF (11 to 33) μF (33 to 110) μF |
1.9 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.01 nF 0.85 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.01 nF 0.37 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.01 nF 0.32 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.3 nF 0.32 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 3 nF 0.32 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 3 nF 0.48 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 30 nF 0.55 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.1 µF |
Fluke 5522A |
Electrical – DC/Low Frequency
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Capacitance – Generate3 |
(110 to 329.999) μF (0.33 to 1.1) mF (1.1 to 3.3) mF (3.3 to 11) mF (11 to 33) mF (33 to 110) mF |
0.53 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.3 µF 0.53 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1 μF 0.53 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 3 μF 0.53 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 10 μF 0.88 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 30 μF 1.3 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.1 mF |
Fluke 5522A |
|
Capacitance – Measure3 50Hz – 100kHz |
0.1 pF to 1 μF (1 to 10) μF 10 μF to 10 mF |
0.7 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 1.3 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 12 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Fluke PM 6304C |
|
Electrical Calibration of Thermocouple Indicating Devices3 – |
Type B (600 to 1 820) °C Type C (0 to 2 316) °C Type E (-250 to 1 000) °C Type J (-210 to 1 200) °C Type K (-200 to 1 372) °C Type L (-200 to 900) °C Type N (-200 to 1 300) °C Type R (0 to 1 767) °C Type S (0 to 1 767) °C Type T (-250 to -200) °C (-200 to 400) °C Type U (-200 to 600) °C |
0.41 °C 0.38 °C 0.29 °C 0.19 °C 0.21 °C 0.12 °C 0.26 °C 0.45 °C 0.44 °C 0.41 °C 0.2 °C 0.19 °C |
Fluke 7526A |
|
Inductance – Measure3 Up to 1 kHz |
10 µH to 637 kH |
0.07 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Fluke PM 6304C |
Electrical – DC/Low Frequency
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Oscilloscope Calibration – Vertical Deflection3 50 Ω, 1 kHz square wave 1 MΩ, 1 kHz square wave Flatness – Leveled Sine Wave 5 mV to 5.5 V ref @ 50 kHz BANDWIDTH Rise Time Time Interval2 |
1 mV to 6.6 V 1 mV to 130 V 50 kHz to 100 MHz (100 to 300) MHz (300 to 600) MHz (600 to 1100) MHz <300 ps (1 to 20) ms 50 ms to 5 s |
0.64 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 40 µV 0.79 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 40 µV 2.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.1 mV 2.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.1 mV 4.6 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.1 mV 6.4 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.1 mV + 33 ps / -120 ps 3 µs/s (25 + 1 000t) µs/s |
Fluke 5522A/SC1100 |
|
Flatness – Measure |
100 mV to 1 V (1 to 40) Hz 40 Hz to 1 kHz (1 to 20) kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz 300 kHz to 1 MHz (1 to 2) MHz (1 to 10) V (1 to 40) Hz 40 Hz to 1 kHz (1 to 20) kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz 300 kHz to 1 MHz (1 to 2) MHz |
0.027 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.04 mV 0.013 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 mV 0.019 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 mV 0.036 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 mV 0.94 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 mV 0.35 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.1 mV 1.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.1 mV 1.7 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.1 mV 0.027 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.4 mV 0.013 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0. 2 mV 0.019 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.2 mV 0.036 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.2 mV 0.94 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.2 mV 0.35 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1 mV 1.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1 mV 1.7 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1 mV |
Fluke 3458A |
|
Power Meter Range Calibration3 |
3 µW to 100 mW |
0.3 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
HP 11683A |
Electrical – RF/Microwave
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Amplitude Modulation3 – Measure 10 kHz to 10 MHz 10 MHz to 3 GHz (3 to 26.5) GHz |
(5 to 99) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}Depth (5 to 20) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}Depth (20 to 99) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}Depth (5 to 20) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}Depth (20 to 99) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}Depth |
1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}Depth 2.9 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}Depth 0.8 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}Depth 5.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}Depth 1.8 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}Depth |
Agilent E4440A |
|
Frequency Modulation3 – Measure 250 kHz to 10 MHz 10 MHz to 6.6 GHz (6.6 to 13.2) GHz (13.2 to 26.5) GHz |
250 Hz to 10 kHz 50 Hz to 200 kHz |
3.1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 3.1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 3.8 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Agilent E4440A |
|
Attenuation3 – Measure 10 MHz to 26.5 GHz |
(-10 to 0) dB (-20 to -11) dB (-30 to -21) dB (-40 to -31) dB (-50 to -41) dB (-60 to -51) dB (-70 to -61) dB (-80 to -71) dB (-90 to -81) dB (-100 to -91) dB (-110 to -101) dB (-120 to -111) dB |
0.039 dB 0.039 dB 0.039 dB 0.039 dB 0.039 dB 0.05 dB 0.05 dB 0.05 dB 0.05 dB 0.05 dB 0.059 dB 0.059 dB |
Agilent E4440A w/ N5532B Sensor |
|
Flatness – Measure |
(0.1 to 1) V 300 kHz to 26.5 GHz (1 to 10) V 300 kHz to 26.5 GHz |
5.4 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.1 mV 5.4 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1 mV |
HP 8482A/8485A |
|
AM Distortion3 – Measure |
(0.3to 10) MHz 10 MHz to 26.5 GHz |
1.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 1.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Agilent E4440A |
|
FM Distortion3 – Measure |
1 MHz to 50 GHz |
0.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Agilent E4440A |
Electrical – RF/Microwave
Length – Dimensional metrology
Length – Dimensional metrology
Mass
Thermodynamic
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Relative Humidity – Generate |
(10 to 95) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}RH |
0.51 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}RH |
Thunder Scientific 1200 |
|
Relative Humidity – Measure |
(0 to 90) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}RH |
1.7 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}RH |
Vaisala HM141/HMP46 |
|
Temperature – Measuring Equipment3 |
(-25 to 140) °C |
0.13 °C |
1502A with 5615 SPRT and dry block |
|
Temperature – Measure3 |
(-200 to 420) °C |
0.04 °C |
Hart 1502A/5615 SPRT |
Time and Frequency
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Frequency – Measure |
10 MHz |
1 x 10-11 Hz/Hz |
58503A/B GPS |
|
Frequency – Measure3 |
10 Hz to 225 MHz 225 MHz to 26.5 GHz |
3 x 10-9 Hz/Hz 2 x 10-7 Hz/Hz |
HP 53131A, E4440A |
Calibration and Measurement Capability (CMC) is expressed in terms of the measurement parameter, measurement range, expanded uncertainty of measurement and reference standard, method, and/or equipment. The expanded uncertainty of measurement is expressed as the standard uncertainty of the measurement multiplied by a coverage factor of 2 (k=2), corresponding to a confidence level of approximately 95{3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}.
Notes:
1. On-site calibration service is available for this parameter, since on-site conditions are typically more variable than those in the laboratory, larger measurement uncertainties are expected on-site than what is reported on the accredited scope.
2. L = length in inches, D = diameter in inches, R = resolution of device under test, t = time in seconds, DL = diagonal length in inches.
3. This scope is formatted as part of a single document including Certificate of Accreditation No. AC-2080.03.
Version 003 Issued: March 14, 2018 www.anab.org
