SCOPE OF ACCREDITATION TO ISO/IEC 17025:2017, ANSI/NCSL Z540-1-1994 (R2002) AND ANSI/NCSL Z540.3-2006 (R2013)
Technical Maintenance, Inc.
12530 Telecom Drive
Temple Terrace, FL 33637
Scott Chamberlain 813-978-3054
CALIBRATION
Valid to: September 20, 2019
Certificate Number: AC-2080
Acoustics and Vibration
|
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
|
Accelerometers – Acceleration (7 < 10) Hz (10 < 30) Hz (30 < 2000) Hz (2 to 10) kHz |
(0.01 to 10) g |
4 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 3 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 1.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 4 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Accelerometer Calibrator |
Chemical Quantities
|
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
|
pH meters1 |
(4, 7, 10) pH |
0.02 pH |
pH buffer solutions |
|
Conductivity Meters1 |
2 µS 10 µS 100 µS 1 000 µS 10 000 µS |
0.52 µS 0.25 µS 0.47 µS 2.8 µS 95 µS |
Conductivity solutions |
|
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
|
Phase Angle – Generate 1 Hz to 1 kHz 1 to 6.25 kHz 6.25 to 50 kHz 50 to 200 kHz 1 Hz to 1 kHz 1 to 6.25 kHz 6.25 to 50 kHz 50 to 200 kHz |
(0 to 360) ° 5 V Equal Amplitude (0 to 360) ° 50 mV to 100 V |
0.005 ° 0.01 ° 0.016 ° 0.04 ° 0.006 ° 0.01 ° 0.017 ° 0.057 ° |
Clarke-Hess 5500-2 |
|
Phase Angle – Measure 5 Hz to 2 kHz 2 to 5 kHz 5 to 10 kHz 10 to 50 kHz 50 to 100 kHz 100 to 200 kHz |
0° to 360° 10 mV to 350 V |
0.02 ° 0.03 ° 0.04 ° 0.05 ° 0.1 ° 0.2 ° |
Clarke-Hess 6000A |
|
DC Current – Generate1 |
Up to 220 μA 220 μA to 2.2 mA 2.2 to 22 mA 22 to 220 mA 220 mA to 2.2 A |
40 µA/A + 6 nA 35 µA/A + 7 nA 36 µA/A + 40 nA 48 µA/A + 0.7 µA 81 µA/A + 12 µA |
Fluke 5730A |
|
(2.2 to 11) A |
370 µA/A + 480 µA |
Fluke 5730A/5725A |
|
|
(11 to 20.5) A (20 to 100) A |
77 µA/A + 1 mA 79 µA/A + 6 mA |
Fluke 5522A/52120A |
|
|
DC Current Clamp Meters Toroidal |
(100 to 550) A (500 to 1 025) A |
|
Fluke 5522A/Coil5500A |
|
DC Current Clamp Meters Non-Toroidal |
(100 to 550) A (500 to 1 025) A |
|
Fluke 5522A/52120A/6KA/Coil |
|
DC Current – Measure1 |
(0.004 to 220) μA 220 μA to 2.2 mA (2.2 to 22) mA (22 to 220) mA |
6 µA/A
10 µA/A |
Fluke 8508A/5450A |
|
(0.22 to 2.2) A (2.2 to 25) A |
37 µA/A 25 µA/A |
Fluke 8508A/Guildline 9230A |
|
|
(25 to 100) A (100 to 1 000) A |
0.25 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 1.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.5A |
Fluke 8508A/Empro 250A Fluke 376 Clamp |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
DC Voltage1 – Generate |
0 to 220 mV 220 mV to 2.2 V (2.2 to 11) V (11 to 22) V (22 to 220) V (220 to 1 100) V |
11 µV/V + 0.4 µV 5.2 µV/V + 0.7 µV 3.5 µV/V + 2.5 µV 3.5 µV/V + 4 µV 5.0 µV/V + 40 µV 6.5 µV/V + 400 µV |
Fluke 5730A |
|
DC Voltage1 – Measure |
Up to 200 mV 200 mV to 2 V (2 to 20) V (20 to 200) V (200 to 1 000) V |
15 µV/V + 100 nV 3.8 µV/V + 400 nV 3.5 µV/V + 4 µV 5.5 µV/V + 40 µV 5.5 µV/V + 500 µV |
Fluke 8508A |
|
(1 to 120) kV |
0.23 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Ross VD120/ HP34401A |
|
|
DC Voltage1 – Measure Fixed Points |
100 mV 1V 10V 100V 1 000V |
2.9 µV/V 0.83 µV/V 0.33 µV/V 0.5 µV/V 0.73 µV/V |
Fluke 732A/752A |
|
AC Voltage – Generate1 |
(0.22 to 2.2) mV (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz (2.2 to 22) mV (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz |
0.027 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 μV 0.014 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 μV 0.013 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 μV 0.022 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 μV 0.052 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 5 μV 0.11 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 10 μV 0.14 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 20 μV 0.27 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 20 μV 0.024 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 μV 91 μV/V + 4 μV 81 μV/V + 4 μV 0.02 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 μV 0.05 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 5 μV 0.1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 10 μV 0.14 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 20 μV 0.27 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 20 μV |
Fluke 5730A |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
AC Voltage – Generate1 |
(22 to 220) mV (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz 220 mV to 2.2 V (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz (2.2 to 22) V (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz (22 to 220) V (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz |
0.024 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 12 μV 90 μV/V + 7 μV 58 μV/V + 7 μV 0.012 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 7 μV 0.031 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 17 μV 0.066 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 20 μV 0.14 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 25 μV 0.27 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 45 μV 0.024 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 40 μV 90 μV/V + 15 μV 43 μV/V + 8 μV 67 μV/V + 10 μV 85 μV/V + 30 μV 0.034 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 80 μV 0.1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 200 μV 0.17 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 300 μV 0.024 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 400 μV 91 μV/V + 150 μV 43 μV/V + 50 μV 67 μV/V + 100 μV 83 μV/V + 200 μV 0.025 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 600 μV 0.1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 2 mV 0.15 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 3.2 mV 0.024 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 mV 90 μV/V + 1.5 mV 52 μV/V + 0.6 mV 80 μV/V + 1 mV 0.015 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 2.5 mV |
Fluke 5730A/5725A |
|
AC Voltage – Generate1 |
(220 to 750) V 40 Hz to 1 kHz (1 to 20) kHz (20 to 50) kHz (50 to 100) kHz |
91 μV/V + 4 mV 0.017 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 6 mV 0.06 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 11 mV 0.23 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 45 mV |
Fluke 5730A/5725A |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
AC Voltage – Generate1 |
(750 to 1 000) V 40 Hz to 1 kHz (1 to 20) kHz (20 to 30) kHz |
91 μV/V + 4 mV 0.017 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 6 mV 0.06 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 11 mV |
Fluke 5730A/5725A |
|
AC Voltage – Measure1 |
Up to 2.2 mV (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz (2.2 to 7) mV (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz (7 to 22) mV (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz (22 to 70) mV (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz |
0.13 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1.3 μV 0.058 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1.3 μV 0.034 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1.3 μV 0.063 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 2 μV 0.093 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 2.5 μV 0.18 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 μV 0.18 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 8 μV 0.24 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 8 μV 0.065 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1.3 μV 0.028 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1.3 μV 0.016 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1.3 μV 0.031 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 2 μV 0.046 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 2.5 μV 0.091 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 μV 0.099 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 8 μV 0.18 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 8 μV 0.022 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1.3 μV
0.024 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 2.5 μV 0.062 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 μV 0.068 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 8 μV 0.13 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 8 μV 0.018 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1.5 μV 91 μV/V + 1.5 μV 50 μV/V + 1.3 μV 99 μV/V + 2 μV 0.02 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 2.5 μV 0.039 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 μV 0.051 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 8 μV 0.084 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 8 μV |
Fluke 5790A |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
AC Voltage – Measure1 |
(70 to 220) mV (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz (220 to 700) mV (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz 700 mV to 2.2 V (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz (2.2 to 7) V (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz |
0.016 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1.5 μV 65 μV/V + 1.5 μV 31 μV/V + 1.3 μV 27 μV/V + 2 μV 0.012 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 2.5 μV 0.019 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 μV 0.029 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 8 μV 0.076 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 8 μV 0.022 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 1.5 μV 91 μV/V + 1.5 μV 60 μV/V + 1.3 μV 72 μV/V + 2 μV 94 μV/V + 2.5 μV 0.019 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 μV 0.031 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 8 μV 0.097 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 8 μV 0.015 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 50 μV/V 20 μV/V 35 μV/V 54 μV/V 0.012 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.02 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.069 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.015 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 51 μV/V 19 μV/V 37 μV/V 63 μV/V 0.015 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.031 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.091 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Fluke 5790A |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
AC Voltage – Measure1 |
(7 to 22) V (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz 500 kHz to 1 MHz (22 to 70) V (10 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (100 to 300) kHz (300 to 500) kHz (70 to 220) V (10 to 20) Hz (20 to 40) Hz 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (220 to 700) V 40 Hz to 20 kHz (20 to 50) kHz (50 to 100) kHz (700 to 1 000) V 40 Hz to 20 kHz (20 to 30) kHz |
0.015 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 52 μV/V 22 μV/V 37 μV/V 62 μV/V 0.015 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.031 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.091 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.015 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 52 μV/V 25 μV/V 44 μV/V 72 μV/V 0.015 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.015 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 53 μV/V 24 μV/V 53 μV/V 75 μV/V 35 μV/V 0.01 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.038 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 33 μV/V 0.01 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Fluke 5790A |
|
AC Voltage – Measure1 |
(1 to 85) kV (50, 60) Hz |
0.67 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Ross VD120/ HP 34401A |
|
AC Current – Measure1 |
(9 to 220) μA (10 to 20) Hz (20 to 40) Hz 40 Hz to 1 kHz (1 to 5) kHz (5 to 10) kHz |
0.025 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 16 nA 0.016 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 10 nA 0.01 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 8 nA 0.028 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 12 nA 0.11 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 65 nA |
Fluke 5730A |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
AC Current – Measure1 |
(0.22 to 2.2) mA (10 to 20) Hz (20 to 40) Hz 40 Hz to 1 kHz (1 to 5) kHz (5 to 10) kHz (2.2 to 22) mA (10 to 20) Hz (20 to 40) Hz 40 Hz to 1 kHz (1 to 5) kHz (5 to 10) kHz (22 to 220) mA (10 to 20) Hz (20 to 40) Hz 40 Hz to 1 kHz (1 to 5) kHz (5 to 10) kHz |
0.025 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 40 nA 0.016 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 35 nA
0.011 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 650 nA 0.025 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 400 nA 0.016 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 350 nA
0.011 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 5 µA 0.025 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 4 μA 0.016 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 3.5 μA
0.11 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 10 μA |
Fluke 5730A |
|
AC Current – Generate1 |
(0.22 to 2.2) A 20 Hz to 1 kHz (1 to 5) kHz (5 to 10) kHz (2.2 to 11) A 40 Hz to 1 kHz (1 to 5) kHz (5 to 10) kHz |
0.025 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 35 μA 0.045 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 80 μA 0.7 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 160 μA 0.046 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 170 μA 0.095 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 380 μA 0.36 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 750 μA |
Fluke 5730A/5725A |
|
AC Current – Generate1 |
(11 to 20.5) A (45 to 100) Hz 100 Hz to 1 kHz (1 Hz to 5) kHz |
0.1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 2 mA 0.12 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 5 mA 2.3 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 5 mA |
Fluke 5520A |
|
AC Current Clamps – Toroidal Clamps -Non-Toroidal |
(10 to 125) A (45 to 65) Hz (10 to 150) A (65 to 440) Hz (10 to 125) A (45 to 65) Hz (10 to 150) A (65 to 440) Hz |
0.24 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading +0.34A 0.61 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading +0.11A 0.44 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading +0.95A 0.76 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading +0.91A |
Fluke 5522A/x50 Coil |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
AC Current Clamps – Rogowski |
(100 to 6000)A (20 to 1 000) Hz |
0.6 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading +0.3 A |
Fluke 52120/6KA/Coil |
|
AC Current – Measure1 |
Up to 200 μA (1 to 10) Hz 10 Hz to 10 kHz (10 to 30) kHz (30 to 100) kHz 200 μA to 2 mA (1 to 10) Hz 10 Hz to 10 kHz (10 to 30) kHz (30 to 100) kHz |
0.054 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 μA 0.054 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 μA 0.074 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 μA 0.4 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.02 μA 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.2 μA 0.031 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.2 μA 0.072 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading+ 0.2 μA 0.4 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.2 μA |
Fluke 8508A |
|
AC Current – Measure1 |
(2 to 22) mA (10 to 20) Hz (20 to 40) Hz 40 Hz to 1 kHz (1 to 10) kHz (10 to 50) kHz (22 to 220) mA (10 to 20) Hz (20 to 40) Hz 40 Hz to 1 kHz (1 to 10) kHz (10 to 50) kHz |
0.021 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.012 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.01 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.01 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.014 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.045 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.042 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.041 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.041 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.019 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Fluke 5790A / Holt HCS-1 Current Shunts |
|
AC Current – Measure1 |
(0.22 to 2.2) A (10 to 20) Hz (20 to 40) Hz 40 Hz to 1 kHz (1 to 10) kHz (10 to 50) kHz (2.2 to 20) A (10 to 20) Hz (20 to 40) Hz 40 Hz to 1 kHz (1 to 10) kHz |
86 μA/A 54 μA/A 48 μA/A 76 μA/A 0.019 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 97 μA/A 64 μA/A 60 μA/A 91 μA/A |
Fluke 5790A / Holt HCS-1 Current Shunts |
|
AC Current – Measure1 |
(100 to 1 000) A (10 to 100) Hz (100 to 500) Hz |
1.6 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.5A 1.9 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading+ 0.5A |
Fluke 376 |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
AC Current – Measure1 |
(200 to 600) A (10 to 500) Hz (600 to 2 500) A (10 to 500) Hz |
2.3 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.5A 2.3 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 5A |
Fluke 376 W/i2500 flex probe |
|
Resistance – Generate, Fixed Points1 |
1 Ω 10 Ω 100 Ω 1 kΩ 10 kΩ 100 kΩ 1 MΩ 10 MΩ 19 MΩ 100 MΩ 1 GΩ |
1.7 μΩ/Ω 1.6 μΩ/Ω 2.1 μΩ/Ω 1.3 μΩ/Ω 1.1 μΩ/Ω 4.2 μΩ/Ω 2.4 μΩ/Ω 5.6 μΩ/Ω 7.3 μΩ/Ω 34 μΩ/Ω 104 μΩ/Ω |
Fluke 742A/ IET SRL |
|
(1, 1.9) Ω (10, 19) Ω (100, 190) Ω (1, 1.9) kΩ (10, 19) kΩ (100, 190) kΩ 1 MΩ 1.9 MΩ 10 MΩ 19 MΩ 100 MΩ |
98 μΩ/Ω 23μΩ/Ω 10 μΩ/Ω 6.5 μΩ/Ω 6.5 μΩ/Ω 8.5 μΩ/Ω 13 μΩ/Ω 18 μΩ/Ω 40 μΩ/Ω 48 μΩ/Ω 100 μΩ/Ω |
Fluke 5730A |
|
|
Resistance – Generate1 |
Up to 11 Ω (11 to 33) Ω (33 to 110) Ω (110 to 330) Ω 330 Ω to 1.1 kΩ (1.1 to 3.3) kΩ (3.3 to 11) kΩ (11 to 33) kΩ (33 to 110) kΩ (110 to 330) kΩ |
40 μΩ/Ω + 0.01 Ω 30 μΩ/Ω + 0.015 Ω 28 μΩ/Ω + 0.015 Ω 28 μΩ/Ω + 0.02 Ω 29 μΩ/Ω + 0.02 Ω 29 μΩ/Ω + 0.2 Ω 29 μΩ/Ω + 0.1 Ω 29 μΩ/Ω + 1 Ω 29 μΩ/Ω + 1 Ω 33 μΩ/Ω + 10 Ω |
Fluke 5520A |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Resistance – Generate1 |
(0.33 to 1.1) MΩ (1.1 to 3.3) MΩ (3.3 to 11) MΩ (11 to 33) MΩ (33 to 110) MΩ (110 to 330) MΩ (0.33 to 1.1 GΩ |
33 μΩ/Ω + 10 Ω 60 μΩ/Ω + 150 Ω 0.013 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 250 Ω 0.025 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 2.5 kΩ 0.05 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 3 kΩ 0.3 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 100 kΩ 1.5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 500 kΩ |
Fluke 5520A |
|
Resistance – Measure1 Fixed Points |
1 Ω 10 Ω 100 Ω 1 kΩ 10 kΩ 100 kΩ 1 MΩ 10 MΩ 100 MΩ 1 GΩ |
9.2 μΩ/Ω 3.7 μΩ/Ω 2.3 μΩ/Ω 1.5 μΩ/Ω 1.4 μΩ/Ω 4.4 μΩ/Ω 3.2 μΩ/Ω 6.1 μΩ/Ω 34 μΩ/Ω 194 μΩ/Ω |
Fluke 8508A/ Fluke 742A/ IET SRL |
|
Resistance – Measure1 |
Up to 2 Ω (2 to 20) Ω (20 to 200) Ω 200 Ω to 2 kΩ (2 to 20) kΩ (20 to 200) kΩ 200 kΩ to 2 MΩ (2 to 20) MΩ (20 to 200) MΩ 200 MΩ to 2 GΩ (2 to 20) GΩ |
19 μΩ/Ω + 4 µΩ 9.5 μΩ/Ω + 14 µΩ 8 μΩ/Ω + 50 µΩ 8 μΩ/Ω + 500 µΩ 8 μΩ/Ω + 5 mΩ 8 μΩ/Ω + 50 mΩ 9.0 μΩ/Ω + 1 Ω 17 μΩ/Ω + 10Ω 65 μΩ/Ω + 1kΩ 0.018 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 100 kΩ 0.15 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 10 MΩ |
Fluke 8508A |
|
Capacitance – Generate1 |
(0.19 to 0.109) nF (1.1 to 3.299) nF (3.3 to 329.999) nF (0.33 to 1.099) μF (1.1 to 3.299) μF (3.3 to 10.999) μF (11 to 32.999) μF (33 to 109.999) μF |
1.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.01 nF 1.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.01 nF 0.39 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 0.3 nF 0.38 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 3 nF
0.53 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 30 nF 0.58 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 100 nF |
Fluke 5522A |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Capacitance – Generate1 |
(110 to 329.999) μF (0.33 to 1.099) mF (1.1 to 3.299) mF (3.3 to 10.999) mF (11 to 32.999) mF (33 to 110) mF |
0.58 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 300 nF
0.65 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 30 μF 1.3 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 100 μF |
Fluke 5522A |
|
Capacitance – Measure 12 Hz to 200 kHz |
0.000 01 pf to 99 999 µf |
0.026 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
IET 1693 |
|
Capacitance – Generate1 Fixed Points |
1 pF 10 pF 100 pf 1 000 pF |
0.41 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.17 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.13 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.32 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Agilent 16380A |
|
Inductance – Measure 12 Hz to 200 kHz |
0.01 µH to 99 999 H |
0.025 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
IET 1693 |
|
Inductance – Generate 1 kHz |
0.07 µH 0.1 µH 0.28 µH 0.52 µH 1 µH 2.5 µH 5.2 µH 10 µH 28 µH 56 µH 100 µH 250 µH 520 µH 1 mH 2.8 mH 5.2 mH |
0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Agilent 16470A |
|
Inductance – Generate 1 kHz |
10 mH 25 mH 52 mH |
0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.032 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Agilent 16470A |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Oscilloscope Calibration – Vertical Deflection1 50 Ω, 1 kHz square wave 1 MΩ, 1 kHz square wave Flatness – Leveled Sine Wave Bandwidth Rise Time Time Interval2 |
1 mV to 6.6 V 1 mV to 130 V 5 mV to 5.5 V 50 kHz to 100 MHz (100 to 300) MHz (300 to 600) MHz (600 to 1100) MHz <300 ps 1 ns to 20 ms 50 ms to 5 s |
0.25 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 40 µV 0.1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 40 µV 1.7 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 100 µV 2.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 100 µV 4.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 100 µV 5.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading + 100 µV + 13 ps / -101 ps 2.7 μs/s (26 + 1 000t) μs/s |
Fluke 5522A/SC1100 |
|
Power Meter Range Calibration1 |
3 μW to 100 mW |
0.25 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
HP 11683A |
|
Electrical Calibration of Thermocouple Indicating Devices1 – |
Type B (600 to 1 820) °C Type C (0 to 2 316) °C Type E (-250 to 1 000) °C Type J (-210 to 1 200) °C Type K (-200 to 1 372) °C Type L (-200 to 900) °C Type N (-200 to 1 300) °C |
0.41 °C 0.38 °C 0.29 °C 0.19 °C 0.21 °C 0.12 °C 0.26 °C |
Fluke 7526A |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Electrical Calibration of Thermocouple Indicating Devices1 – |
Type R (0 to 1 767) °C Type S (0 to 1 767) °C Type T (-250 to -200) °C (-200 to 400) °C Type U (-200 to 600) °C |
0.45 °C 0.44 °C 0.41 °C 0.2 °C 0.19 °C |
Fluke 7526A |
Electrical – RF/Microwave
|
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
|
Flatness – Measure |
1mV to 7 V (10 to 30) Hz (30 to 120) Hz 120 Hz to 1.2 kHz (1.2 to 120) kHz (120 to 500) kHz 500 kHz to 1.2 MHz (1.2 to 2) MHz (2 to 10) MHz (10 to 20) MHz (20 to 30) MHz |
0.16 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.04 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.04 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.04 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.04 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.06 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.06 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.12 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.19 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.43 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Fluke 5790A |
|
Flatness – Measure |
Up to 7 V 30 MHz to 50 GHz |
6 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
HP 8487A/8482A |
|
Attenuation1 – Measure 100 kHz to 50 GHz 100 kHz to 50 GHz 100 kHz to 50 GHz 100 kHz to 50 GHz 100 kHz to 50 GHz 100 kHz to 50 GHz 100 kHz to 50 GHz 100 kHz to 45 GHz 100 kHz to 41 GHz |
(-10 to 0) dB (-20 to -11) dB (-30 to -21) dB (-40 to -31) dB (-50 to -41) dB (-60 to -51) dB (-70 to -61) dB (-80 to -71) dB (-90 to -81) dB |
0.019 dB 0.022 dB 0.027 dB 0.032 dB 0.037 dB 0.055 dB 0.06 dB 0.064 dB 0.069 dB |
Agilent N5531S |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Attenuation1 – Measure 100 kHz to 31.15 GHz 100 kHz to 26.5 GHz 100 kHz to 3.05 GHz |
(-100 to -91) dB (-110 to -101) dB (-120 to -111) dB |
0.074 dB 0.086 dB 0.091 dB |
Agilent N5531S |
|
Amplitude Modulation1 – Measure 100 kHz to 10 MHz 10 MHz to 3 GHz 10 MHz to 3 GHz (3 to 26.5) GHz (3 to 26.5) GHz (26.5 to 31.5) GHz (26.5 to 31.5) GHz (31.5 to 50) GHz (31.5 to 50) GHz |
(5 to 99) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth (5 to 20) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth (20 to 99) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth (5 to 20) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth (20 to 99) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth (5 to 20) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth (20 to 99) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth (5 to 20) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth (20 to 99) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth |
1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth 2.9 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth 0.8 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth 5.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth 1.8 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth 7.9 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth 2.3 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth 30 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth 7 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} Depth |
Agilent N5531S |
|
Frequency Modulation1 – Measure 250 kHz to 10 MHz 10 MHz to 6.6 GHz (6.6 to 13.2) GHz (13.2 to 31.15) GHz (31.15 to 50) GHz |
20 Hz to 10 kHz (50 to 200) Hz |
3.1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 3.1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 3.8 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 5 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 11 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Agilent N5531S |
|
Phase Modulation1 – Measure |
100 kHz to 50 GHz |
9.7 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Agilent N5531S |
|
AM Distortion1 – Measure |
(0.1 to 10) MHz 10 MHz to 26.5 GHz (26.5 to 50) GHz |
0.8 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 6.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Agilent N5531S |
|
FM Distortion1 – Measure |
1 MHz to 50 GHz |
0.3 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Agilent N5531S |
|
Attenuation Generate 30 MHz 30 MHz 30 MHz 30 MHz 30 MHz |
10 dB 20 dB 30 dB 40 dB 50 dB |
5.6 mdB 7.6 mdB 6.4 mdB 7.4 mdB 8.6 mdB |
HP 11812A |
|
RF Power1 – Measure 50 MHz |
1.0 mW |
0.0032 mW |
HP 478A/Opt H76 |
|
RF Power1 – Measure 100 kHz-4.2 GHz |
(-30 to 0.01) dBm (0.01 to 20) dBm |
1.1 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
HP 8482A-H84 |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
RF Power1 – Measure 10 MHz-18 GHz |
(-30 to -0.01) dBm (0.01 to 20) dBm |
1.3 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
HP 8481A-H84 |
|
RF Power1 – Measure 10 MHz-26.5GHz |
(-20 to -0.01) dBm 0.01 to 30) dBm |
4.7 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Agilent N5531S |
|
RF Power1 – Measure 100 kHz to 4.2 GHz |
(0.01 to 44) dBm |
4.1{3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
HP 8482B |
|
RF Power1 – Measure 50 MHz to 50 GHz |
(-30 to -0.01) dBm (0.01 to 20) dBm |
2.7 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
HP 8487A-H84 |
|
RF Power – Generate 10 Hz – 100 kHz 100 kHz – 10 MHz 10 MHz – 128 MHz 128 MHz – 300 MHz |
(-48 to 24) dBm (-48 to 24) dBm (-74 to -48) dBm (-94 to -74) dBm (-48 to 24) dBm (-84 to -48) dBm (-94 to -84) dBm (-130 to -94) dBm (-48 to 20) dBm (-74 to -48) dBm (-84 to -74) dBm (-94 to -84) dBm (-130 to -94) dBm |
0.035 dB 0.058 dB 0.23 dB 0.58 dB 0.058 dB 0.12 dB 0.35 dB 0.81 dB 0.081 dB 0.12 dB 0.35 dB 0.58 dB 1.8 dB |
Fluke 9640A-LPNX |
|
RF Power – Generate 300 MHz – 1.4 GHz 1.4 GHz – 3 GHz 3 GHz – 4 GHz |
(-48 to 20) dBm (-74 to -48) dBm (-84 to -74) dBm (-94 to -84) dBm (-130 to -94) dBm (-48 to +14) dBm (-74 to -48) dBm (-94 to -74) dBm (-130 to -94) dBm (-17 to 14) dBm (-74 to -17) dBm (-84 to -74) dBm |
0.23 dB 0.46 dB 0.58 dB 1.2 dB 1.8 dB 0.35 dB 0.58 dB 1.2 dB 1.8 dB 0.35 dB 0.58 dB 1.2 dB |
Fluke 9640A-LPNX |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Phase Noise1 – SSB Measure |
1 MHz to 50 GHz |
0.39 dB |
Agilent E4448A |
|
AM/FM Distortion1 |
20 Hz to 20 kHz |
1.2 dB |
HP 8903B |
|
Harmonic Distortion 20 Hz to 20 kHz 20 kHz to 50 GHz |
(0 to -120) dB |
1.2 dB 1.2 dB |
HP 8903B Agilent E4448 |
|
LISN and CDN Impedance LISN and CDN Phase* *(dependent on reflection magnitude) Insertion Loss 9 kHz – 500 MHz |
0.1 Ω to 5 kΩ (-180 to 180) ° (-30 to 10) dB (-40 to -30) dB (-50 to -40) dB (-50 to -40) dB (-70 to -60) dB (-80 to -70) dB |
1.7{3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 1.4 ° 0.034 dB 0.062 dB 0.12 dB 0.35 dB 1 dB 3.5 dB |
8751A System w/ 87511A and 85032B |
|
CISPR 16-1-1 Pulse Band A (9 to 150) kHz Band B (0.15 to 30) MHz Band C & D (30 to 1 000) MHz |
(-80 to 80) dB (-80 to 80) dB (-80 to 80) dB |
0.65 dB 0.65 dB 1.1 dB |
Schwarzbek IGUU-2918 |
|
Return Loss (VSWR) 5 Hz to 45 MHz 45 MHz to 50 GHz |
(0 to 120) dB (0 to 120) dB |
1.1 dB 0.41 dB |
HP 8751A HP 85107B |
|
ESD Simulator Current Measure Current Rise Time |
(0.02 to 50) A 10 ps to 10 ms |
4{3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 3.2 ps + 25 µs/s |
Tektronix CSA7404B w/ Haefely PET 4000 |
|
EFT/Burst Generator Duration Measure Risetime Measure Amplitude Measure |
(0.05 to 1 000) µs 0.3 ns to 100 ms 10 V to 8 kV |
290 µs/s 0.2 ns + 290 µs/s 3.3{3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Lecroy 7100A w/ Teseq CAS 3025 EFT attenuator set |
|
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
|
Gage Blocks2 |
Up to 20 in |
(1.7+2.1L) μin |
Master gage blocks, P&W universal measuring machine |
|
Micrometers1,2 |
Up to 40 in |
(32 + 4L) μin |
Gage blocks (grade 2) |
|
Calipers1,2 |
Up to 40 in |
(48 + 7.2L) μin |
Gage blocks (grade 2) |
|
Dial Indicators1,2 |
Up to 10 in |
(86 + 46L) μin |
Gage blocks (grade 2) |
|
Height Gages1,2 |
Up to 40 in |
(194 + 3L) μin |
Gage blocks (grade 2) |
|
Protractors1 |
(0 to 360) ° |
0.01 ° |
Angle blocks |
|
Rulers1 |
Up to 46 in |
0.009 in |
Gage blocks (grade 2) |
|
Feeler Gage1 |
Up to 1 in |
74 µin |
Pratt & Whitney Supermicrometer C |
|
Cylindrical Gages1,2 – Plain Pin, Plugs, Rings |
(0.04 to 14) in |
(8 + 2D) μin |
Master gage blocks, P&W universal measuring machine |
|
Cylindrical Gages1,2 – Plain Rings |
(0 to 13) in |
(2 + 3D) μin |
|
|
Thread Plugs1 – Major Diameter Pitch Diameter |
Up to 12 in Up to 12 in |
40 μin 91 μin |
B & S 599-246-00, Van Keuren thread wire set Gage blocks, Pratt & Whitney Labmaster |
|
Thread Rings |
Up to 12 in |
107 μin |
Pratt & Whitney Labmaster, Thread setting plug gages |
|
Thread Wires |
Up to 0.5D |
10 μin |
Master gage blocks, P&W universal measuring machine |
|
Surface Plates1 – Overall Flatness Local Area Flatness |
Up to 6 ft 6 ft Up to 18 x 18 in |
95 μin 74 uin |
Planekator Repeat-O-Meter |
|
Optical Comparators1 – Linearity Magnification |
Up to 20 in (20 to 40) in (10 to 100) x |
590 μin 790 μin 590 μin |
Gage blocks, SI Industries glass scales |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Coating Thickness Gages1,2 – Eddy Current & Magnetic Induction |
(0.737 to 100) mils (100 to 243) mils |
26 μin 240 μin |
Coating thickness standards |
|
Coating Thickness Shims |
(0 to 243) mils |
90 μin |
Pratt & Whitney Supermicrometer C |
Mass
|
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
|
Scales & Balances1,2 |
(1 to 20) g (20 to 200) g (200 to 5 000) g (11 to 100) lb |
0.09 mg + 0.6R 0.58 mg + 0.6R 14 mg + 0.6R 0.06 g + 0.6R |
Class 1 weights |
|
Up to 1 000 lb |
55 g + 0.6R |
Class F weights |
|
|
Force – Tension and Compression1 |
(0.5 to 500) lbf |
0.09 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Class F weights |
|
(200 to 10 000) lbf (10 000 to 25 000) lbf (25 000 to 50 000) lbf |
0.011 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Morehouse Press with Load Cells |
|
|
Pressure1 |
(0 to 24) inH2O |
0.0025 inH2O |
Dwyer 1425-25 |
|
(-15 to 200) psi (0 to 1 000) psi |
0.013 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading or 0.003 9{3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading of PPC4 Span (whichever is greater) |
Fluke PPC4 |
|
|
(10 to 16 000) psi |
0.019 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Fluke P3125-PSI Dead Weight Tester |
|
|
Gas Flow |
(1 to 10 000) sccm (10 000 to 100 000) sccm |
0.29 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.64 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Molbloc flow standards |
|
Torque Tools1 |
(16 to 64) ozf-in 64 ozf-in to 1 000 lbf-ft |
1.5{3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading 0.32{3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
Mountz S320 |
|
Torque Analyzers1 |
1 lbf-in to 1 000 lbf-ft |
0.1{3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} of reading |
CDI 5000 ST |
|
Parameter/Equipment |
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
Indirect Verification of Rockwell Hardness Testers1 |
(40 to 59) HRBW (59.1 to 79) HRBW (79.1 to 100) HRBW (25 to 30) HRC (35 to 55) HRC (59 to 65) HRC (70 to 79) HR15EW (84 to 90) HR15EW (93 to 100) HR15EW (74 to 80) HR15TW (81 to 86) HR15TW (87 to 93) HR15TW |
1.9 HRBW 1.3 HRBW 1.3 HRBW 1.3 HRC 1.3 HRC 0.73 HRC 1.3 HREW 1.3 HREW 1.3 HREW 1.8 HR15TW 1.3 HR15TW 1.3 HR15TW |
Indirect verification per ASTM E18 |
|
Mass |
(1, 2, 5) g 10 g 20 g 50 g 100 g 200 g 500 g 1 kg 5 kg 0.03125 oz 0.0625 oz 0.125 oz 0.25 oz 0.5 oz (0.001, 0.002) lb (0.005, 0.01, 0.02) lb 0.05 lb
5 lb 10 lb 25 lb 50 lb |
0.09 mg 0.09 mg 0.09 mg 0.33 mg 0.53 mg 0.73 mg 29 mg 30 mg 30 mg 0.18 mg 0.18 mg
0.19 mg
0.31 mg 0.31 mg 0.36 mg 31 mg 31 mg 0.11 g 0.16 g 0.16 g |
Comparison to ASTM E617 Class 1 weights |
|
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
|
Relative Humidity Generate |
(10 to 95) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} RH |
0.51 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} RH |
Thunder Scientific 2500 |
|
Relative Humidity Measure |
(0 to 90) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} RH (90 to 100) {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} RH |
1.2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} RH 2 {3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443} RH |
Vaisala MI70/HMP76 |
|
Temperature – Measure1 |
(-25 to 600) C |
0.025 C |
Hart 1502A with 5616 PRT |
|
(800 to 1 550) ºC |
2 ºC |
Type B Thermocouple |
|
|
IR Thermometry1 |
(50 to 100) ºC (100 to 300) ºC (300 to 500) ºC |
0.51 ºC 0.61 ºC 0.8 ºC |
Fluke 9132 |
Time and Frequency
|
Range |
Expanded Uncertainty of Measurement (+/-) |
Reference Standard, Method, and/or Equipment |
|
|
Frequency – Measure |
10 MHz |
1 x 10-11 Hz/Hz |
58503A/B GPS |
|
Frequency – Measure1 |
10 Hz to 46 GHz (46 to 50) GHz |
1 x 10-9 Hz/Hz 1 x 10-8 Hz/Hz |
HP 53152A, E4448A |
Calibration and Measurement Capability (CMC) is expressed in terms of the measurement parameter, measurement range, expanded uncertainty of measurement and reference standard, method, and/or equipment. The expanded uncertainty of measurement is expressed as the standard uncertainty of the measurement multiplied by a coverage factor of 2 (k=2), corresponding to a confidence level of approximately 95{3abc3950d4f1f8f388f3ff046375d7d82c013b00bce2a30b1200ecdfc3f73443}.
Notes:
-
On-site calibration service is available for this parameter, since on-site conditions are typically more variable than those in the laboratory, larger measurement uncertainties are expected on-site than what is reported on the accredited scope.
-
L = length in inches, 1 mil = 0.001 inch, D = diameter in inches, t = time in seconds, R = resolution of device under test.
-
This scope is formatted as part of a single document including Certificate of Accreditation No. AC-2080.
